Direct Ring
총 22개 모델
| No. | 모델 | 색상 / 소비전력(W) | 치수 | 전압 | LED 수량 | 자료 |
|---|---|---|---|---|---|---|
| 1 | W / B / G 1.5 / 1.5 / 1.5 |
outer Ø32, inner Ø19, height 20mm | 12V | 18EA | ||
| 2 | W / B / G 1.7 / 1.7 / 1.7 |
outer Ø37, inner Ø24, height 20mm | 12V | 21EA | ||
| 3 | W / R / B / G 2.9 / 1.5 / 2.9 / 2.9 |
outer Ø40, inner Ø20, height 20mm | 12V | 36EA | ||
| 4 | W / B / G 2.9 / 2.9 / 2.9 |
outer Ø46, inner Ø15, height 22.1mm | 12V | 36EA | ||
| 5 | W / R / B / G 3.4 / 1.7 / 3.4 / 3.4 |
outer Ø50, inner Ø20, height 17mm | 12V | 42EA | ||
| 6 | W / R / B / G 3.9 / 1.9 / 3.9 / 3.9 |
outer Ø60, inner Ø30, height 22mm | 12V | 48EA | ||
| 7 | W / R / B / G 8.7 / 4.4 / 8.7 / 8.7 |
outer Ø64, inner Ø20, height 22mm | 12V | 108EA | ||
| 8 | W / R / B / G 7.2 / 3.6 / 7.2 / 7.2 |
outer Ø66, inner Ø26, height 22.5mm | 12V | 90EA | ||
| 9 | JL-R-D-70x35-3P | W / R / B / G 8.7 / 4.4 / 8.7 / 8.7 |
outer Ø70, inner Ø35, height 22mm | 12V / 24V | 108EA |
–
|
| 10 | W / R / B / G 10.6 / 5.3 / 10.6 / 10.6 |
outer Ø74, inner Ø28.8, height 20mm | 12V | 132EA | ||
| 11 | W / R / B / G 8.7 / 4.3 / 8.7 / 8.7 |
outer Ø74, inner Ø35, height 22mm | 12V | 108EA | ||
| 12 | W / R / B / G 6.8 / 3.4 / 6.8 / 6.8 |
outer Ø80, inner Ø55, height 22mm | 12V | 84EA | ||
| 13 | W / R / B / G 7.7 / 3.9 / 7.7 / 7.7 |
outer Ø87, inner Ø53, height 24mm | 12V / 24V | 96EA | ||
| 14 | W / R / B / G 18.8 / 9.4 / 18.8 / 18.8 |
outer Ø90, inner Ø28.8, height 20mm | 12V | 234EA | ||
| 15 | W / R / B / G 11.6 / 5.8 / 11.6 / 11.6 |
outer Ø90, inner Ø50, height 22mm | 12V | 144EA | ||
| 16 | W / R / B / G 19.2 / 9.6 / 19.2 / 19.2 |
outer Ø120, inner Ø70, height 24mm | 12V / 24V | 240EA | ||
| 17 | W / R / B / G 21.6 / 10.8 / 21.6 / 21.6 |
outer Ø150, inner Ø47, height 20mm | 12V | 270EA | ||
| 18 | W / R / B / G 14.4 / 7.2 / 14.4 / 14.4 |
outer Ø163, inner Ø130, height 24mm | 12V / 24V | 180EA | ||
| 19 | W / R / B / G 33.2 / 16.6 / 33.2 / 33.2 |
outer Ø170, inner Ø112, height 24mm | 12V / 24V | 414EA | ||
| 20 | W / R / B / G 24 / 12 / 24 / 24 |
outer Ø200, inner Ø130, height 33mm | 12V / 24V | 300EA | ||
| 21 | W / R / B / G 40.8 / 20.4 / 40.8 / 40.8 |
outer Ø240, inner Ø85, height 35mm | 12V / 24V | 510EA | ||
| 22 | W / R / B / G 36.5 / 18.3 / 36.5 / 36.5 |
outer Ø240, inner Ø110, height 35mm | 12V / 24V | 456EA |
표를 좌우로 밀어 전체 사양을 확인하세요.
