COAXIAL
총 16개 모델
| No. | 모델 | 색상 / 소비전력(W) | 치수 | 전압 | LED 수량 | 자료 |
|---|---|---|---|---|---|---|
| 1 | W / R / B / G 2 / 1 / 2 / 2 |
W 50mm x D 30mm x H 27mm | 12V | 24EA | ||
| 2 | W / R / B / G 2 / 1 / 2 / 2 |
W 50.5mm x D 32mm x H 32mm | 12V | 16EA | ||
| 3 | W / R / B / G 8.7 / 4.4 / 8.7 / 8.7 |
W 69.7mm x D 52.5mm x H 50.5mm | 12V / 24V | 36EA | ||
| 4 | W / R / B / G 5.8 / 2.9 / 5.8 / 5.8 |
W 73mm x D 50mm x H 49mm | 12V | 72EA | ||
| 5 | W / R / B / G 8.7 / 4.4 / 8.7 / 8.7 |
W 69.7mm x D 52.5mm x H 50.5mm | 12V / 24V | 36EA | ||
| 6 | W / R / B / G 2.9 / 1.5 / 2.9 / 2.9 |
W 87mm x D 54mm x H 54mm | 12V | 36EA | ||
| 7 | W / R / B / G 8.7 / 4.4 / 8.7 / 8.7 |
W 73mm x D 67.6mm x H 49mm | 12V / 24V | 108EA | ||
| 8 | W / R / B / G 10.6 / 5.3 / 10.6 / 10.6 |
W 81mm x D 67.6mm x H 57mm | 12V / 24V | 132EA | ||
| 9 | W / R / B / G 19.2 / 9.6 / 19.2 / 19.2 |
W 105mm x D 75mm x H 75mm | 12V / 24V | 240EA | ||
| 10 | W / B / G 19.5 / 19.5 / 19.5 |
W 112mm x D 74mm x H 73mm | 12V | 81EA | ||
| 11 | W / R / B / G 26 / 13 / 26 / 26 |
W 115mm x D 104mm x H 81mm | 12V / 24V | 108EA | ||
| 12 | W / R / B / G 24.5 / 12.3 / 24.5 / 24.5 |
W 111mm x D 87.6mm x H 87mm | 12V / 24V | 306EA | ||
| 13 | W / R / B / G 40.8 / 20.4 / 40.8 / 40.8 |
W 150mm x D 115mm x H 85mm | 12V / 24V | 510EA | ||
| 14 | W / R / B / G 23 / 11.5 / 23 / 23 |
W 120mm x D 155mm x H 85mm | 12V | 288EA | ||
| 15 | W / R / B / G 28.4 / 5.8 / 11.6 / 11.6 |
W 206mm x D 169mm x H 164mm | 12V | 144EA | ||
| 16 | W / R / B / G 69.2 / 34.6 / 69.2 / 69.2 |
W 160mm x D 334mm x H 110mm | 12V | 864EA |
표를 좌우로 밀어 전체 사양을 확인하세요.
